| SUKAN
supplies
diamond grinding covers suitable for fast removal and leveling of rough
granite, marble, concrete and other materials |
|
Recommended
RPM
Wheel
diameter(mm) |
105
|
115 |
125 |
150 |
180 |
200
|
230 |
Max
RPM |
15300 |
13300
|
12300
|
10200
|
8500
|
7700
|
6650 |
M/S |
80 |
80 |
80 |
80 |
80 |
80 |
80 |
|
Recommended
Pressure :
1~5kgs/cm2
Diamond grit size:
| Coarse
: 30/40, 40/50 mesh |
| Medium
: 80/100 , 100/120 mesh |
| Fine
: 170/200, 200/230 mesh |
|
SINGLE
ROW DIAMOND GRINDING COVERS
-Grinding
for fast removal and smooth finish.
- Cost effective. |
PART
# |
Diameter
|
ARBOR
|
Segment
Dimension |
Number
of segments |
Inch |
mm |
Inch |
mm |
Length
|
Width
|
Height |
DGSS414
|
4
1/4
|
105
|
7/8-5/8 |
22.2-15.9 |
30 |
5.0 |
8.0
|
8 |
DGSS413
|
4
1/3
|
110
|
7/8-5/8 |
22.2-15.9 |
30 |
5.0 |
8.0
|
8 |
DGSS412
|
4
1/2 |
115
|
7/8-5/8 |
22.2-15.9 |
30 |
5.0 |
8.0
|
9 |
DGSS500
|
5
|
125
|
7/8-5/8 |
22.2-15.9 |
30 |
5.0 |
7.2
|
10 |
DGSS700
|
7
|
180
|
7/8-5/8 |
22.2-15.9 |
30 |
5.0 |
7.8
|
12 |
DGSS800
|
8
|
200
|
7/8-5/8 |
22.2-15.9 |
30 |
5.0 |
7.8
|
14 |
DGSS900 |
9 |
230 |
7/8-5/8 |
22.2-15.9 |
30 |
5.0 |
7.8 |
16 |
|
 |
|
DOUBLE
ROW DIAMOND GRINDING COVERS
-
Grinding for fast removal and smooth finish.
- Faster grinding with long life. |
PART
# |
Diameter
|
ARBOR
|
Segment
Dimension |
Number
of segments |
Inch |
mm |
Inch |
mm |
Length
|
Width
|
Height |
DGSD410
|
4
|
100
|
7/8-5/8 |
22.2-15.9 |
30/23
|
5.0 |
8.0
/ 7.2
|
16 |
DGSD414
|
4
1/4
|
105
|
7/8-5/8 |
22.2-15.9 |
30/23 |
5.0 |
8.0
/ 7.2
|
16 |
DGSD412
|
4
1/2 |
115
|
7/8-5/8 |
22.2-15.9 |
30/23 |
5.0 |
8.0
/ 7.2
|
18 |
DGSD500
|
5
|
125
|
7/8-5/8 |
22.2-15.9 |
32/20 |
5.0 |
7.2
|
20 |
DGSD700
|
7
|
180
|
7/8-5/8 |
22.2-15.9 |
35/28 |
5.0 |
7.8
|
24 |
DGSD800
|
8
|
200
|
7/8-5/8 |
22.2-15.9 |
35/28 |
5.0 |
7.8
|
28 |
DGSD900 |
9 |
230 |
7/8-5/8 |
22.2-15.9 |
35/28 |
5.0 |
7.8 |
32 |
|
 |
|
TURBO
TYPE DIAMOND GRINDING COVERS
-
Grinding for aggressive grinding of concrete and masonry.
- More surface area for a faster cleaner cut. |
PART
# |
Diameter
|
ARBOR
|
Segment
Dimension |
Number
of segments |
Inch |
mm |
Inch |
mm |
Width |
Height |
DGST410
|
4
|
100
|
7/8-5/8 |
22.2-15.9 |
5.0
|
20 |
20 |
DGST414
|
4
1/4
|
105
|
7/8-5/8 |
22.2-15.9 |
5.0 |
20 |
20 |
DGST412
|
4
1/2 |
115
|
7/8-5/8 |
22.2-15.9 |
5.0 |
20 |
25 |
DGST500
|
5
|
125
|
7/8-5/8 |
22.2-15.9 |
5.0 |
20 |
30 |
DGST700
|
7
|
180
|
7/8-5/8 |
22.2-15.9 |
5.0 |
20 |
40 |
|
 |
|
OTHER
SIZES AND SPECIFICATIONS ARE AVAILABLE UPON REQUEST
|
